Name: 6 Contacts Metal Cable Connector Natural Chrome Plated Black Bend Relief
Brand: Shenzhen Raymo Electronics Technology Limited
SKU: RM-FGG-1BC-306JS52Z
Price: 11.10 USD
Availability: InStock

6 Contacts Metal Cable Connector Natural Chrome Plated Black Bend Relief

বেসিক ইনফরমেশন

উৎপত্তি স্থল:	গুয়াংডং, চীন
পরিচিতিমুলক নাম:	RAYMO
সাক্ষ্যদান:	ISO9001:2015 CE ROHS2.0 REACH SGS
Model Number:	RM-FGG-1BC-306JS52Z

ন্যূনতম চাহিদার পরিমাণ:	1 পিসি
মূল্য:	negotiable
প্যাকেজিং বিবরণ:	300PCS/CTN
ডেলিভারি সময়:	1-7 কার্যদিবস
পরিশোধের শর্ত:	এল/সি, ডি/এ, ডি/পি, টি/টি, ওয়েস্টার্ন ইউনিয়ন, মানিগ্রাম
যোগানের ক্ষমতা:	প্রতি সপ্তাহে 50000pcs

এখন যোগাযোগ

কীওয়ার্ডস:

ধাক্কা টানা

Prct name:

Cable male connector

লিঙ্গ:

পুরুষ

Shell size:

00B,0B,1B,2B,3B,4B,5B

Contact no:

2,3,4,5,6,.7,8,9,10,12,14,16,21,26,30,32

আইপি স্তর:

আইপি 50

Insulator Material:

PPS, PEEK

Endurance:

>5000times cycle

Material:

natural/black chrome plated brass

আবেদন:

অডিও এবং ভিডিও

Temperature:

- 80Celsius Degree~ +350Celsius Degree,

প্রকার:

দিন

বিশেষভাবে তুলে ধরা:

electronics component connectors

cable connector plug

prcts discription

Part No.example:

RM-FGG-1BC-306JS52Z=FGG.1B.306.JS52Z

Explanation : FGG: straight plug, 1B : 1B size of outer shell, C: natural-chrome plated , 306: 6 contacts. JS: male contact in solder; 52: 52 cable collect for Ø4.2-5.2mm cable, Z: with black bend relief

6 Contacts Metal Cable Connector Natural Chrome Plated Black Bend Relief 3

Main Features :

1. Security of the push-pull self-latching system.
2. 100% compatible with original connectors;
3. Multipole from 2 to 32pin contacts available
4. Key option: 1 key(G) & 2 key with different degree:30°,45°,60°,90°,...145°
5. 360°screening for full EMC shielding.
6. High packing density for space savings

7. Cable assembly as customers real needs (OEM is available)
8. Certification: CE, ROHS, Reach, SIO9001,SGS

9. Fast delivery ( 3-15 working days )

Prction Series	B series	Type	B series FGG straight plug
Compability	100% compatible with original connector	Endurance	>5000 cycle
Shell Material	Brass with pearl-chrome/black-chrome	Temperature range	-55°C, +250°C
Shell Size	00,0B,1B,2B,3B	Humidity (max)	<=95% [at 60 deg C /140 F]
Contact Material	Brass(Gold plated)	Vibration	15 g [10 Hz - 2000 Hz]
Contact No.	2-32 pins	Shock Resistance	100 g [ 6 ms]
Gendar	Male / female	Salt Spray Corrosion	>96 hr
Contact type	For solder/print(PCB)/90° PCB	Climatical Category	55/175/21
Insulator Material	PPS	Conductor	AWG
Cable Ø	Ø1~11mm	Rated Voltage	≤200V
Keying	1 key(G) & 2 key with different degree	Rated Current
Certificate	CE/RoHs/Reach/ISO9001/SGS	Shielding (min)	75 dB (10 MHz) 40 dB (1 GHz)
MOQ	1 pcs	IP Rating	IP 50

Size	Contact no.
00	2,3,4
0B	2,3,4,5,6,7,9
1B	2,3,4,5,6,7,8,10,12,14,16
2B	2,3,4,5,6,7,8,10,12,14,16,18,19,26, 0
3B	3,4,7,8,10,12,14,16,18,21,30,32

Colour : Brass with Natural-chrome plated

6 Contacts Metal Cable Connector Natural Chrome Plated Black Bend Relief 6

Colour : Brass with Black-chrome plated

Colour : Brass with Black-chrome plated 6 Contacts Metal Cable Connector Natural Chrome Plated Black Bend Relief 7

FAQ

1. What is the MOQ?
Raymo: No MOQ limited, small order is accepted, all is depend on customer real needs.

2. Are your company a professional manufacturer?

Raymo: Yes, we specialized in prcing Circular Connectors and cable assembly since 2010.
Our factory is SGS audited manufacturer and worked on www.alibaba.com more than 9 years.

3. Free sample?
Raymo: Available. Any needs, please contact us.

4. What about the delivery time?
Raymo: sample for 3-5 working days, mass prction for 5-7 working days.

5.What is your payment terms?
Raymo: 100% T/T deposit when customer place order.

6. Does your prct have any warranty?
Raymo: Yes, all of our connectors can work normally after 5000 cycles mating; our factory has instruments to tested them before shipping.
Damage due to misuse, treatment and unauthorized modifications and repairs are not covered by our warranty.

If you couldn't find exact items you want,PLS kindly email us exact models you need, best price & each model specification details will be provided to you soon. Solve the original brand's high cost and long lead time!
